  • Specifications


    Model CKS 400A-HV CKS 750A-HV CKS1500A-HV CKS 2200A-HV
    Performance Cooling capacity ※1 kW 1.3 2.2 5.3 8.7
    Ambient temperature 5 45 5 40
    Temperature control 5 40 5 30
    Pressure range MPa 0.08 0.13 0.08 0.14 0.15 ~ 0.5
    Control accuracy ※4 ±0.1
    Flow rate L/min 10 25 10 53
    Power Power source ※2 V 1ph 220±10% 50Hz 3ph 380±10% 50Hz
    Power consumption※1 kW 0.9 1 2.7 4.4
    Electric current ※1 A 3.8 6 12.6 7.8
    Power capacity※3 kVA 1.5 1.8 3 5.6
    Breaker capacity A 15 Overload protection breaker 15 30 20
    Operation control method Electronic expansion valve capacity control + Compressor ON/OFF control
    Equipment details Compressor Construction Fully sealed rotary type Fully sealed scroll type
    Output kW 0.6 0.75 1.61 3
    Condenser Corrugated fin & Tube type parallel flow condenser Fin and tube forced air cooling
    Heat exchanger Construction Plate type heat exchanger
    Material SUS 316(Brazing :Cu)
    Discharge pump Construction Magnetism Forle Pumps Multistage centrifugal immersion type
    Output W 85 600 580
    Water tank capacity L Approx 17 Approx 24 Approx 34 Approx 44
    Refrigerant R-410A
    Outside dimensions (H × D × W) mm 500×375×641 681×400×886 851×432×982 951×530×1137
    Unit mass (dry weight) kg 46 76 105 155
    *1 CKS400A-HV: Chilled water temp.: 20℃ and Ambient temp.: 25℃, Max. discharge pump circulating load. Cooling capacity is at least 95 % of listed figures. Other models: Chilled water temp.: 20℃ and Ambient temp.: 30℃ at maximum water flow of discharge pump. Cooling capacity is at least 95 % of listed figures.

    *2 Source voltage phase unbalance should be less than ±3 %.

    *3 The figure noted is when operating at the highest capacity in the normal operating range.

    *4 CKS400A-HV: When the current load is continuously within ±10 %. When the load is light, the compressor is operated by ON/OFF control. Other models: When the current load is stably 80% at rated conditions. When the load is light, the compressor is operated by ON/OFF control.
